Main Features :
Device status: after the device is turned on, it will be connected to the network automatically. When the connection is successful, it will broadcast "network normal".
Anti misreading card: the default anti misreading interval is 1 minute, that is, the same card can only be swiped once in 1 minute on the same card reader; the anti misreading interval can be changed.
Beidou Positioning: after the card reader searches for the BD/GPS satellite, the number on the left side of the display screen changes to the lowercase letter "d". At this time, the device has searched for the satellite.
Data synchronization of card reader: after the card reader is connected to the network, it will automatically synchronize data to the server.
When the students get on and off the bus and swipe the card, the parents immediately receive the reminder of SMS, which is convenient for parents to pick up and drop off, so as to avoid the situation that the children are lost.
The driver/teacher can check the student sign in form on the mobile phone, and can know the situation that the students get on and off the bus in detail
The card reader can automatically compare the information of students getting on and off the bus to avoid students staying on the bus.
All student cards adopt the real name system. When students punch in, the card reader will broadcast their names.
The equipment adopts high-quality power supply scheme, and works stably in all kinds of vehicle tests; the equipment has passed a variety of harsh environment tests, such as high temperature, low temperature, high humidity and dust particles, to protect the safety of children.
Product Technical Parameters: |
||
Item |
Parameters |
Performance |
System |
Display |
Led Display |
|
Communication module |
Built in GSM、GPRS |
|
Interface |
1 power interface |
|
Data synchronization |
Yes |
|
Powerinput |
10V ~ 32V, with automatic recovery function of overvoltage and undervoltage |
|
Power consumption |
about 2W |
|
Operating temperature |
-20℃~+70℃ |
|
Store Temperature |
-30℃~+80℃ |
|
IC card frequency |
13.56MHZ |
|
Weight |
0.3KG |
|
Size |
150*150*34（mm) |
